SF6 Load Break Switches
SF6 load break switches designed for 10/20kV distribution networks. Compact, reliable switching with auto-detection and fault isolation capabilities.
SPG-12 Outdoor SF6 Load Break Switch (12kV)
The SPG-12 is a 12kV outdoor SF6 load break switch for 10kV distribution systems. Uses SF6 pressure-assisted arc blowing in a 304 stainless steel molded housing — low gas pressure means low heat, short extinguishing time, and long life. Features low gas pressure interlock (locks operation at 0.03-0.04 MPa with visual alarm), manual interlock for safe maintenance, and high-pressure explosion-proof relief (0.4-0.6 MPa with side venting, no solid particle ejection). Silicone rubber/epoxy resin insulation with APG integral vacuum casting — 20+ years outdoor proven. Every unit X-ray inspected. Triangle spring mechanism sealed in SF6 housing — rust-free, maintenance-free. Capable of zero-gauge-pressure rated current switching. 5,000 mechanical operations life.
SPG-24 Outdoor SF6 Load Break Switch (24kV)
The SPG-24 is a 24kV outdoor SF6 load break switch for 20kV distribution systems. Enhanced insulation levels with 125/145kV lightning impulse withstand. Same proven SF6 pressure-assisted arc blowing technology in 304 stainless steel housing. Available in 630A and 1250A rated current variants. Features all safety interlocks (low pressure, manual, explosion-proof relief). Silicone rubber/epoxy resin insulation with APG vacuum casting. Every unit X-ray inspected. 5,000 mechanical operations life.
SF6 Load Break Switches from NAIJI Electric
Outdoor SF6 gas-insulated load break switches for pole-mounted applications. Suitable for urban distribution networks as sectionalizing or tie switches.
As a professional manufacturer with 25+ years of experience, NAIJI Electric produces high-quality products that meet international standards including IEC 62271. Our products are exported to more than 20 countries across Southeast Asia, Middle East, Africa, Latin America, and CIS regions.
All products undergo rigorous factory testing including power frequency withstand, lightning impulse withstand, and mechanical endurance tests before shipment. We offer both standard models and custom configurations to meet your project-specific requirements.
Related Technical Articles
In-depth guides from NAIJI Electric engineers to help you select and specify sf6 load break switches.
SF6 Load Break Switch: What It Is & How It Works
Technical guide to SF6 load break switches (LBS) for medium-voltage distribution. Covers operating principles, ratings, ring main unit applications, SF6 gas handling, and alternatives.
What Is a Ring Main Unit (RMU)? 5 Types Compared
SF6 vs solid-insulated vs hybrid — which RMU fits your 12–24 kV network? Compare 5 types with selection chart, IEC 62271 ratings, and factory-direct pricing.
SF6-Free Switchgear: EU F-Gas 2030 Ban & 4 Alternatives
SF6-free MV switchgear options: vacuum, dry air, nitrogen & C4F7N compared side by side. EU F-Gas 2030 ban timeline, 15-year cost analysis & spec guide. Manufacturer with SF6-free lines in production. Quote →
Frequently Asked Questions
What types of sf6 load break switches does NAIJI Electric manufacture?
What is the lead time for sf6 load break switches?
Does NAIJI Electric offer OEM manufacturing for sf6 load break switches?
What certifications do your sf6 load break switches carry?
Need LBS for Your Project?
Contact our technical team for product selection, pricing, and custom configurations.
